| Type | AUSD - 40 | AUSD - 125 | |
| Rated Current | A | 16, 20, 25, 32, 40 | 63, 80, 100, 125 |
| Rated Voltage | V | 400/415 | |
| Rated Insulation Voltage(Ui) | V | 800 | |
| Rated Thermal Current at 40℃ (Ith) | A | 16, 20, 25, 32, 40 | 63, 80, 100, 125 |
| Rated Frequency | Hz | 50/60 | |
| Number of Poles | 3P | ||
| Rated Impulse Withstand Voltage (Uimp) | kV | 8 | |
| Rated Short - time Withstand Current (Icw) | A | 600/1s | 1500/1s |
| Rated Short - circuit Making Capacity (Icm) | A | 800 | 2500 |
| Utilization Category | AC - 22A | ||
| Mounting | 35mm DIN Rail Mounting, Screw Mounting | ||
| Cable Termination | mm² | 10 | 25 - 50 |
| Protection Degree | IP20 | ||
