| Rated Current (In) | A | 10, 13, 16, 20, 25, 32, 40, 50, 63, 80, 100, 125 |
| Rated Voltage (Ue) | V | 230/240, 400/415 |
| Number of Poles | 1P, 2P, 3P, 4P, 1P+N, 3P+N | |
| Rated Breaking Capacity | Ultimate (Icu) | 20(In=10-63A), 10(In=80-125A)kA |
| Service (Ics) | 15(In=10-63A), 7.5(In=80-125A)kA | |
| Rated Frequency | Hz | 50/60 |
| IP Degree | IP20 | |
| Tripping Characteristics | C=8In, D=12In | |
| Electrical Endurance | Cycles | 4000 |
| Mechanical Endurance | Cycles | 10000 |
| Rated Insulation Voltage (Ui) | V | 500 |
| Rated Impulse Withstand Voltage (Uimp) | kV | 6 |
| Cable Termination | mm² | 50 |
| Torque Screw | N.m | 3.0 |
| Terminal | Pillar Type |
