| Rated Current (In) | A | 0.5, 1, 2, 3, 4, 6, 10, 13, 16, 20, 25, 32, 40, 45, 50, 63 |
| Rated Voltage (Ue) | V | 480V/277 |
| Number of Poles | 1P, 2P, 3P | |
| Rated Breaking Capacity | Ultimate (Icn) | 10kA |
| Service (Ics) | 7.5kA | |
| Rated Frequency | Hz | 50/60 |
| IP Degree | IP20 | |
| Tripping Characteristics | B, C, D | |
| Energy Limiting Class | - | |
| Electrical Endurance | Cycles | 4000 |
| Mechanical Endurance | Cycles | 10000 |
| Rated Insulation Voltage (UI) | V | 500 |
| Rated Impulse Withstand Voltage (Uimp) | kV | 4 |
| Cable Termination | mm² | 25 |
| Torque Screw | N.m | 2.5 |
| Terminal | Pillar Type |
