| Rated Current (In) | Without time delay | A | 16, 25, 40, 63, 80, 100 |
| With time delay(Type S) | 40, 63, 80, 100 | ||
| Rated Voltage (Ue) | V | 240, 415 | |
| Number of Poles | 1P+N, 3P+N | ||
| Rated Breaking Capacity | kA | Inc= IΔc= 10 | |
| Rated Residual Current (IΔn) | mA | 30, 100, 300 | |
| Residual Tripping Characteristics | AC, A | ||
| Rated Residual Making and Breaking Capacity (IΔm) | A | 1000 | |
| Rated Frequency | Hz | 50/60 | |
| Max. Back-up Fuse | In=16 - 63A 63Ag/gI | ||
| In=80A 80AGg/gI | |||
| In=100A 100AGg/gI | |||
| IP Degree | IP20 | ||
| Energy Limiting Class | - | ||
| Electrical Endurance | Cycles | 2000 | |
| Mechanical Endurance | Cycles | 10000 | |
| Rated Impulse Withstand Voltage (Uimp) | kV | 4 | |
| Cable Termination | mm² | 35 | |
| Torque Screw | N.m | 2.5 | |
| Terminal | Pillar Type | ||
