| KSP(MOV) | KSP(GDT/NPE) | |||
| Rated Working Voltage of Uo | V | 230(1N50Hz) | - | |
| Nominal Discharge Current 8/20μs (In) | kA | 20 | 20 | |
| Max. Discharge Current 8/20μs (Imax) | kA | 40 | 40 | |
| Max. Continuous Operating Voltage (Uc) | V | 275 |
320 385 |
255 |
| Voltage Protection Level (Up) | kV | ≤1.3 |
≤1.5 ≤1.8 |
≤1.3 |
| Gas Discharge Tube | - | with | ||
| Wiring Capacity | mm² | L/N2.5 | PE4 | L/N2.5 PE4 |
| Protection Class IP | IP20 | IP20 | ||
| Material | PA66 | PA66 | ||
| Local Indicator | Green Indicates Normal State and Red Indicates Failure | |||
| The Outer Flame Retardant Grade | Comply with UL94V-0 | |||
| Remote Communication Contact | Adding X at the End of Type, eg: KSP | |||
