| Rated Current (In) | A | 6, 10, 13, 16, 20, 25, 32, 40 | ||
| Rated Voltage (Ue) | V | 240 | ||
| Number of Poles | 1P+N | |||
| Rated Breaking Capacity | Ultimate (Icu) | kA | 10 | |
| Service (Ics) | kA | 7.5 | ||
| Rated Residual Current (IΔn) | mA | 10, 30, 100, 300 | ||
| Residual Tripping Characteristics | AC, A | |||
| Rated Residual Making and Breaking Capacity (IΔm) | A | 6000 | ||
| Rated Frequency | Hz | 50/60 | ||
| IP Degree | IP20 | |||
| Tripping Characteristics | B,C | |||
| Energy Limiting Class | 3 | |||
| Electrical Endurance | Cycles | 4000 | ||
| Mechanical Endurance | Cycles | 10000 | ||
| Rated Insulation Voltage (Ui) | V | 500 | ||
| Rated Impulse Withstand Voltage (Uimp) | kV | 4 | ||
| Cable Termination | mm² | 16 | ||
| Torque Screw | N.m | 1.2 | ||
| Terminal | Pillar Type | |||
