| Rated Current (In) | A | 20, 25, 40, 63, 80, 100, 125 | |
| Rated Operational Voltage (Ue) | V | 230/400 | |
| Control Voltage (Uc) | V | 24/48/110/230 | |
| Number of Module | 1M, 2M, 3M | ||
| Rated Frequency | Hz | 50/60 | |
| Utilization Category | AC1, AC3, AC7a, AC7b, AC5b | ||
| Electrical Endurance | Cycles | 150,000 (AC1, AC7a); 150,000 (AC3, AC7b) | |
| Mechanical Endurance | Cycles | 1,000,000 | |
| Rated Insulation Voltage (Ui) | V | 500 | |
| Rated Impulse Withstand Voltage (Uimp) | kV | 4 | |
| Terminals | Pillar Type | ||
| Cable Termination | mm² | 16/25 | |
| Torque of Screw | N.m | 1.2/2 | |
| IP Degree | IP20 | ||
