KDOH 10KA RCBO

Superior K | Residual Current Breaker with Over-Current

Function and Feature

Bi-directional RCBO

A 2P RCBO,each pole has circuit protected and residual current protection enhanced safety
Allows more poles to be fitted into a consumer unit offering a more economy solution

Capacity complies with most energy authority requirements across domestic and overseas installation fault level requirements

Enabling better flexibility of installation as there is no restriction to the top or the bottom connection of the supply

Technical Data

Rated Current (In)		A	6, 10, 13, 16, 20, 25, 32, 40, 50, 63
Rated Voltage (Ue)		V	110, 230/240
Number of Poles			1P+N
Rated Breaking Capacity	Ultimate (Icu)	kA	6
	Service (Ics)	kA	6
Rated Residual Current (IΔn)		mA	30, 50, 100, 300
Residual Tripping Characteristics			AC, A
Rated Residual Making and Breaking Capacity (IΔm)		A	3000
Rated Frequency		Hz	50/60
IP Degree			IP20
Tripping Characteristics			B,C,D
Energy Limiting Class			3
Electrical Endurance		Cycles	4000
Mechanical Endurance		Cycles	10000
Rated Insulation Voltage (Ui)		V	500
Rated Impulse Withstand Voltage (Uimp)		kV	-
Cable Termination		mm²	25
Torque Screw		N.m	2.5
Terminal			Pillar Type
