| Rated Current (In) | A | 63,80,100 | |
| Rated Voltage (Ue) | V | 230/240, 400/415 | |
| Number of Poles | 2P, 3P, 4P | ||
| Rated Breaking Capacity | Ultimate (Icu) | kA | 10 |
| Service (Ics) | kA | 7.5 | |
| Rated Residual Current (IΔn) | mA | 30, 100, 300 | |
| Residual Tripping Characteristics | AC, A | ||
| Rated Residual Making and Breaking Capacity (IΔm) | A | 6000 | |
| Rated Frequency | Hz | 50/60 | |
| IP Degree | IP20 | ||
| Tripping Characteristics | C=8In±20%, D=12In±20% | ||
| Category | Cat.A | ||
| Electrical Endurance | Cycles | 4000 | |
| Mechanical Endurance | Cycles | 10000 | |
| Rated Insulation Voltage (Ui) | V | 500 | |
| Rated Impulse Withstand Voltage (Uimp) | kV | 4 | |
| Cable Termination | mm² | 35 | |
| Torque Screw | N.m | 3.0 | |
| Terminal | Pillar Type |
