| Rated Current (In) | A | 16, 25, 40, 63, 80 | |
| Rated Voltage (Ue) | V | 230/240, 400/415 | |
| Number of Poles | 1P+N, 3P+N | ||
| Rated Breaking Capacity | kA | Inc= IΔc= 10 | |
| Rated Residual Current (IΔn) | mA | 30, 100, 300 | |
| Residual Tripping Characteristics | Type B | ||
| Rated Residual Making and Breaking Capacity (IΔm) | A | 1000 | |
| Rated Frequency | Hz | 50/60 | |
| IP Degree | IP20 | ||
| Energy Limiting Class | - | ||
| Electrical Endurance | Cycles | 2000 | |
| Mechanical Endurance | Cycles | 10000 | |
| Rated Insulation Voltage (Ui) | V | 500 | |
| Rated Impulse Withstand Voltage (Uimp) | kV | 4 | |
| Cable Termination | mm² | 35 | |
| Torque Screw | N.m | 2.5 | |
| Terminal | Pillar Type |
