| Rated Current (In) | A | 80, 100, 125 | |||||
| Number of Poles | 1P | 2P | 3P | 4P | |||
| Rated Voltage (Ue) | V DC |
110/125/ 220/250 |
220/250/ 440/500 |
660/750 | 880/1000 | ||
| Rated Breaking Capacity | Ultimate (Icu) | kA | 10 | ||||
| Service (Ics) | kA | 7.5 | |||||
| Rated Frequency | Hz | 50/60 | |||||
| IP Degree | IP20 | ||||||
| Tripping Characteristics | C:8In D:12In | ||||||
| Energy Limiting Class | - | ||||||
| Electrical Endurance | Cycles | 4000 | |||||
| Mechanical Endurance | Cycles | 10000 | |||||
| Rated Insulation Voltage (Ui) | V | 1000 | |||||
| Rated Impulse Withstand Voltage (Uimp) | kV | 6 | |||||
| Cable Termination | mm² | 50 | |||||
| Torque Screw | N.m | 3.0 | |||||
| Terminal | Pillar Type | ||||||
