| Rated Current (In) | A | 1, 2, 3, 4, 6, 10, 13, 16, 20, 25, 32, 40, 50, 63 | |
| Rated Voltage (Uₑ) | V | 230/240, 400/415 | |
| Number of Poles | 1P, 2P, 3P, 4P, 1P+N, 3P+N | ||
| Rated Breaking Capacity | IEC 60947 - 2 | kA | Iₐₙ=15, Iₙₛ=10 |
| IEC 60898 - 1 | kA | Iₐₙ=15, Iₙₛ=7.5 | |
| Rated Frequency | Hz | 50/60 | |
| IP Degree | IP20 | ||
| Tripping Characteristics | IEC 60947 - 2 | C=li=8In, D=li=12In | |
| IEC 60898 - 1 | B, C, D | ||
| Electrical Endurance | Cycles | 4000 | |
| Mechanical Endurance | Cycles | 10000 | |
| Rated Insulation Voltage (Uᵢ) | V | 500 | |
| Rated Impulse Withstand Voltage (Uᵢₘₚ) | kV | 6 | |
| Cable Termination | mm² | 25 | |
| Torque Screw | N.m | 2.5 | |
| Terminal | Pillar Type |
