| Rated Current (In) | A | 63, 80, 100 |
| Rated Voltage (Uₑ) | V | 230/240, 400/415 |
| Number of Poles | 1P, 2P, 3P, 4P | |
| Rated Breaking Capacity | Ultimate (Iₖₘ) | 10kA |
| Service (Iₙₛ) | 7.5kA | |
| Rated Frequency | Hz | 50/60 |
| IP Degree | IP20 | |
| Tripping Characteristics | C=8In, D=12In | |
| Electrical Endurance | Cycles | 4000 |
| Mechanical Endurance | Cycles | 10000 |
| Rated Insulation Voltage (Uᵢ) | V | 500 |
| Rated Impulse Withstand Voltage (Uᵢₘₚ) | kV | 4 |
| Cable Termination | mm² | 35 |
| Torque Screw | N.m | 3.0 |
| Terminal | Pillar Type |
